Hole Diameter | Staggered Centers | Sheet Thickness | Open Area | ||
0.045" | 1.14mm | 0.066« | 0.033-0.039" | 0.84-0.99mm | 37.00% |
1/16" | 1.59mm | 3/32" | 0.027-0.033" | 0.68-0.84mm | 41.00% |
1/16" | 1.59mm | 1/8" | 0.027-0.066" | 0.68-1.68mm | 23.00% |
5/64" | 1.98mm | 1/8" | 0.027-0.053" | 0.68-1.35mm | 35.00% |
0.081" | 2.06mm | 1/8" | 0.053-0.066" | 1.35-1.68mm | 38.00% |
3/32" | 2.38mm | 5/32" | 0.053-0.066" | 1.35-1.68mm | 33.00% |
1/8" | 3.17mm | 3/16" | 0.027-0.127" | 0.68-3.23mm | 40.00% |
5/32" | 3.97mm | 3/16" | 0.027-0.066" | 0.68-1.68mm | 63.00% |
3/16" | 4.76mm | ¼" | 0.027-0.127" | 0.68-3.23mm | 50.00% |
1/4" | 6.35mm | 3/8" | 0.033-0.111", 0.25" | 0.84-2.82mm, 6.35mm | 40.00% |
3/8" | 9.52mm | ½" | 0.053-0.082", 3/16" | 1.35-2.08mm, 4.76mm | 51.00% |
3/8" | 9.52mm | 9/16" | 0.059", 0.119" | 1.50mm, 3.02mm | 40.00% |
1/2" | 12.70mm | 11/16" | 0.033-0.127", 3/16" | 0.84-3.23mm, 4.76mm | 48.00% |
1/4" Hex | 6.35mm Hex | 0.285 | 0.027-0.033 | 0.68-0.84mm | 76.00% |
Product application
The application of perforated metal:
Used for environmental noise control barriers, such as, highway, railway, subway, etc. As sound-absorbing material of the building ceiling and wall. Protective cover for the machinery and equipment, ornate speaker enclosures. Used as kitchenware, such as, stainless steel fruit basket, food cover, fruit tray, etc. Shopping network with shelves, decorative exhibition units. Grain storage within the ventilation network, soccer turf seepage water treatment network, and so on.
Product packaging
